NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P851 D803 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P851 D804 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P851 D805 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P851 D806 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P851 D807 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P851 D808 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P851 G801 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474K
P851 R826 00MGG05010140 00MGG05010140 RES. ! 1 OHM +-5% 1/4W
P851 R827 00MGG05010140 00MGG05010140 RES. ! 1 OHM +-5% 1/4W
P851 R828 00MGG05010140 00MGG05010140 RES. ! 1 OHM +-5% 1/4W
POWER SW PWB P871
(
00MWG340J604-
)
P871 C891 00MDF77103500 00MDF77103500 FILM CAP. ! 0.01UF M 250V AC
P871 S891 00MSP01012500 00MSP01012500 PUSH SW ! ESB92S13B TV-5 STROKE=1.5MM
VR MODULE PWB ASSY PD71
(
00MWG340J706-
)
PD71 RU57 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
PD71 RU58 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
PD71 RU59 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
PD71 RU60 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
PD71 SU81 00MSR02010140 00MSR02010140 ROTARY SW EC12E2470811
FUSE PWB PF01
(
00MWG340J603-
)
PF01 F871 F N ns
p
0520100140070 FUSE # 0218002.MXP T2A L 250V
PF01 F871
/
K1G ns
p
0520100080020 FUSE # 0218.500MXP T 0.5A L 250V
PF01 F871
/
N1G 0520100080020 0520100080020 FUSE # 0218.500MXP T 0.5A L 250V
PF01 F871
/
U1B ns
p
0520100140070 FUSE # 0218002.MXP T2A L 250V
HDAM-SA S2 PWB PH01
(
00MWA339J701-
)
PH01 DH01 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 DH02 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 DH03 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 DH04 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 JH01 00MYP07005720 00MYP07005720 PLUG IMSA-6065B-06Z074-PT1
PH01 JH02 00MYP07005710 00MYP07005710 PLUG IMSA-6065B-05Z074-PT1
PH01 QH01 00MHT109702A0 00MHT109702A0 TRS. 2SA970 GR OR BL
PH01 QH02 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
PH01 QH03 00MHT109702A0 00MHT109702A0 TRS. 2SA970 GR OR BL
PH01 QH04 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
PH01 QH05 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
PH01 QH06 00MHT109702A0 00MHT109702A0 TRS. 2SA970 GR OR BL
PH01 RH01 ns
p
00MGD05471160 RES. 470 OHM +-5% 1/6W
PH01 RH02 ns
p
00MGD05471160 RES. 470 OHM +-5% 1/6W
PH01 RH03 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
PH01 RH04 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
PH01 RH05 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
PH01 RH06 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
PH01 RH07 ns
p
00MGD05683160 RES. 68K OHM +-5% 1/6W
ID SW PWB PS01
(
00MWG340J710-
)
PS01 R286 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
PS01 R287 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
PS01 R288 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
PS01 R289 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
PS01 R290 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
PS01 S274 00MSR02060190 00MSR02060190 ROTARY SW ROTARY SW SRRM26
MODE SW PWB PS71
(
00MWG340J711-
)
PS71 S273 00MSS02021610 00MSS02021610 SLIDE SW SSSU022-S06N1
U-PRO PWB PU01
(
00MWG340J701-
)
PU01 C210 ns
p
00MOA22605020 ELECT. CAP. 22 UF M 50V RA-2
PU01 C213 ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PU01 C309 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C310 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C311 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C312 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C313 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C341 ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PU01 C351 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C352 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C353 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C354 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PU01 C355 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
