Marantz SR1010 User Manual

FOREWORD
This section must be read before any connection is made to
the mains supply.
l
WARNINGS
Do not expose the equipment to rain or moisture.
Do not remove the cover from the equipment.
Do not push anything inside the equipment through
, the ventilation holes
Do not handle the mains lead with wet hands.
EQUIPMENT MAINS WORKING SETTING
Your Marantz product has been prepared to comply with the
household power and safety requirements that exist in your area.
"102" Version product can be powered by 230 V AC only.
105" or “/07” Version product can be powered by 240 V AC
only.
On the rear panel of the “/01” Version product, a voltage
selector (2-position.or 4-position) is provided. Be sure to set
the voltage selector to the mains voltage of your area before
using the unit.
IMPORTANT:
This apparatus is fitted with an approved moulded 13 Amp
plug. To change a fuse in this type of plug proceed as follows:
4, Remove fuse cover and fuse.
2, Fix new fuse which should be @ BS1362 5A, A.S.T.A. or
BSI approved type.
3, Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, It
should be cut off and an appropriate plug fitted in its place.
{f the mains plug contains a fuse, this should have a value of
5A. If a plug without a fuse is used, the fuse at the distribution
board should not be greater than 5A.
NOTE:
The severed plug must be destroyed to avoid a possible
shock hazard should it be inserted into a 13A socket elsewhere.
HOW TO CONNECT A PLUG
The wires In the mains lead are coloured in accordance with
the following code:
BLUE—"NEUTRAL” (“N")
BROWN—"LIVE” (“L")
1. The BLUE wire must be connected to the terminal which is
marked with the letter "N" or coloured BLACK.
2. The BROWN wire must be connected to the terminal which
is marked with the letter "L" or coloured RED
3, Do not connect either wires to the earth terminal in the
plug which is marked by the letter "E" or by the safety earth
symbol == or coloured green or green-and-yeliow,
Before replacing the plug cover, make certain that the cord
grip is clamped over the sheath of the lead — not simply over
the two wires
COPYRIGHT
Recording and playback of any material may require consent.
For further information refer to the following:
~~ Copyright Act 1956
— Dramatic and Musical Performers Act 1958
— Performers Protection.Acts 1963 and 1972
— any subsequent statutory enactments and orders.
ABOUT THIS USER GUIDE
Refer to the diagrams on page 113 at the rear of this user
guide.. The numbers on the diagrams correspond to those in
the text. All references to the connections and controls that
are printed in BOLD type are as they appear on the unit.
PRECAUTIONS
The following precautions should be taken when operating
the equipment.
GENERAL PRECAUTIONS.
When siting the equipment ensure that:
— the ventilation holes are not covered;
— air is allowed to circulate freely around the equipment
— itis on a vibration free-surface;
— it will not be exposed to interference from an external
source;
— it will not be exposed to excessive heat, cold, moisture or
dust;
— it will not be exposed to direct sunlight;
— it will not be exposed to electrostatic discharges
Never place heavy objects on the equipment.
if a foreign body or water does enter the equipment, contact
your nearest dealer or service centre.
Do not pull out the plug by pulling on the mains lead, hold the
plug.
It is advisable when leaving the house, or during a
thunderstorm, to disconnect the equipment from the mains
supply.
FEATURES
* Top-end models of the Slim Line Series
This model has a very slim shape and a height of 68 mm. All
buttons except for the contro! knobs are conceald behind a
front flap. {SR1020)
* High power output of 50 W + 50 W (DIN, Into 8 ohms)
The discrete configuration is characterised by a high level of
reliability.
© Door open/close mechanism operates by means of a
touch sensor (SR1020)
* 30-Station random preset tuner
Station names consisting of 5 characters can be stored
together with the frequencies.
© Independent/System operation switch
This unit can be operated as a system component in
combination with a CD player and tape deck of the Marantz
Slim Line Series
« 2-Program Timer/Sleep Timer
« System remote control
The remote control supplied with this unit can also be used to
operate the CD player and tape deck of the Marantz Slim
Line Series.
In this manual, the controls on the main unit are enclosed in a
circle, e.g. ©, and the controls on the remote control are
enclosed in a square, ¢.g.
re]
