Connection 2: Connecting using a speaker
output terminal
When “Assign Mode” is set to “ZONE2” in the menu, ZONE2 audio is
output from the HEIGHT2 speaker terminal. (v p. 215)
.
VIDEO
COMPONENT VIDEO
YP
B PR
IN
wq wwq
(L) (R)
MAIN ZONE
ZONE2
This unit
o
Connection 3 : Connection using an external
amplifier (ZONE2)
The audio signals of this unit’s ZONE2 audio output connectors are
output to the ZONE2 amplifiers and played on these amplifiers.
.
VIDEO
COMPONENT VIDEO
YP
B PR
IN
R
L
AUX IN
MAIN ZONE
ZONE2
This unit
Power amplifier
