Connecting 11.1-channel speakers
This system, which is based on a 5.1-channel system, plays back up to 11.1-channels at the same time.
You can connect speakers for 11-channels for MAIN ZONE by using an external power amplifier.
o
Example connection when using two sets of ceiling speakers
.
C
FL FR
SBL
SBR
SW
SL SR
TRL TRR
TFL TFR
0
Set “Height” - “Height Sp” to “4ch” in the menu when connecting in this
configuration. (v p. 218)
.
SBR SBL
TFR TFL
HEIGHT 1
z
TRR TRL
Power amplifier
FR FL C SR SL
SW
HEIGHT 2
z
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v p. 59)
