68
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POWER - SEMICONDUCTORS
D710
9965 000 10728 DIODE IN4007 1000V 1A *HD201570R
D713
D714
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D715
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D719
9965 000 10728 DIODE IN4007 1000V 1A *HD201570R
IC710
4822 209 91031 IC KA7806 *HC300120R
Q711
9965 000 10444 TRS. NPN KRC107M
0.4W/TO92M
*BA001190R
Q712
4822 130 11683 TRS.2SA KSA916Y
0.9W/TO92L-
*HT100600R
Q714
K 9965 000 10444 TRS. NPN KRC107M
0.4W/TO92M
*BA001190R
POWER - MISCELLANEOUS
CN711
K nsp CN WIRE 120MM/2P
35191-02=210-03
BK1617#22 7.92
nsp
CN953
K nsp CN WIRE 120MM/3P
35156-05=210-05 WH1617#22
nsp
CP710
nsp CN.WAFER 2.5MM5267-04A 4P nsp
CP711
nsp CN.WAFER 3.96MM35328-0210 nsp
CP712
nsp CN.WAFER 7.92MM
YW396-32V 2P
nsp
CP713
nsp CN.WAFER 3.96MM35328-0210 nsp
CP714
nsp CN.WAFER 2.0MM
G1L-S-4P-S2T2-EF
nsp
CP715
nsp CN.WAFER 2.0MM
G1L-S-5P-S2T2-EF
nsp
CP741
nsp CN.WAFER 2.0MM
G1L-S-4P-S2T2-EF
nsp
CP951
nsp CN.WAFER 3.96MM35328-0510 nsp
CP953
nsp CN.WAFER 7.92MM
35979-0320 3P ANGLE
nsp
F711
nsp HOLDER FUSE CLIP PI5.2 nsp
F711
K.N 4822 070 32502 FUSE
250V-T2.5A-S/V/B/R(TEAR1)
*FS000770R
F711
nsp FUSE
250V-S2.5A-U/C/
∆
/(TEAR2)
*FS000890R
F712
nsp HOLDER FUSE CLIP PI5.2 nsp
F712
K. nsp FUSE
250V-S8A-R/C/
∆
/(TEAR2)
*FS000900R
F712
N 4822 070 36302 FUSE
250V-T6.3A-S/V/B/R(TEAR1)
*FS000380R
F715
nsp FUSE
250V-S2.5A-U/C/
∆
/(TEAR2)
*FS000890R
F715
U nsp HOLDER FUSE CLIP PI5.2 nsp
F913
K 4822 070 36302 FUSE
250V-T6.3A-S/V/B/R(TEAR1)
*FS000380R
GND711
nsp TERMINAL GND PLATE nsp
GND712
U nsp TERMINAL GND PLATE nsp
J714
nsp JUMPER (0.6/52MM) nsp
J715
nsp JUMPER (0.6/52MM) nsp
J716
nsp JUMPER (0.6/52MM) nsp
L710
nsp COIL FILTER-INDUCTOR
10
µ
H-Q40/24M-R2.5-52RE02TB
nsp
L711
nsp COIL FILTER-INDUCTOR
10
µ
H-Q40/24M-R2.5-52RE02TB
nsp
L712
nsp COIL FILTER-INDUCTOR
10
µ
H-Q40/24M-R2.5-52RE02TB
nsp
RY710
9965 000 11026 RELAY HR-CR7-DC12V/10A *LY000200R
T710
K nsp SUB MAINS TRANSF.
FOR K STAND BY
*TS001550R
T710
N 9965 000 11027 SUB MAINS TRANSF.
FOR N STAND BY
*TS001540R
T710
U nsp SUB MAINS TRANSF.
FOR U STAND-BY
*TS001530R
ZD711
9965 000 11028 D ZENER
MTZJ7.5B-0.5W/5MA-52MM
*HD301980R
ZD712
4822 130 11627 D ZENER
MTZJ15B-0.5W/5MA-52MM
*HD302000R
ZD713
4822 130 11627 D ZENER
MTZJ15B-0.5W/5MA-52MM
*HD302000R
ZD715
4822 130 31554 D ZENER
MTZJ4.3B-0.5W/5MA-52MM
HD30431000
ZD716
nsp D ZENER
MTZJ20B-0.5W/5MA-52MM
*HD301950R
*
K nsp SW SLIDE ESD26832A
AC250V/5A
*SS000720R
*
nsp SUPPORTER AVR1601(KE2)
KIFCO(PS801) /P.C.
nsp
*
nsp SPACER AVC1500(N)
NYLON66 MPS-10-0/CARD
nsp
STBY LED CIRCUIT BOARD
STBY LED-
SEMICONDUCTORS
D303
4822 130 10854 LED SLR-34URCF25 *HI100710R
STBY LED - MISCELLANEOUS
SW325
U 9965 000 10988 SW TACT
SKHV10920A 5MM/260G
*SP000900R
J320
nsp JUMPER (0.6/52MM) nsp
J321
nsp JUMPER (0.6/52MM) nsp
J322
nsp JUMPER (0.6/52MM) nsp
J323
nsp JUMPER (0.6/52MM) nsp
K
K
K
K
N
N
U
U
U
U
U
K
K
K
U
U
U
U
