Marantz ZC4001 - Rear Panel; Remote Control Operation

ENGLISH
4
REAR PANEL
w eq
SERVICE
ONLY
q EXT INPUT
This is the analog audio input. The audio inputs
require RCA-type connectors.
w SERVICE ONLY
This is a servicing port. Do not connect anything to
it.
e AC Power cable
Connect the power outlet on the wall.
REMOTE CONTROL OPERATION
The ZC4001 does not come with a remote controller.
However, it does have an infrared sensor that functions as a remote control signal receptor, and therefore
it can be operated with the system remote controller (RC5500SR, etc.) of other Marantz products.
Remote-controllable range
ThedistancebetweenthetransmitteroftheremotecontrolunitandtheinfraredsensoroftheZC4001
shouldbelessthanabout16.4ft(5meters).
Ifthetransmitterispointedawayfromtheinfraredsensororifthereisanobstaclebetweenthem,remote
controlmaynotbepossible.
60°
Approx. 5 m
