Marathon CL030078 - Device Backing Overview; Back Panel Controls

Atomic Alarm Clock Backing
B1: SNOOZE/LIGHT button
B2: ALARM ON/OFF slide switch
B3: button
B4: - button
B5: + button
B6: button
B7: RESET button
B8: °C/°F button
B9: DST ON/OFF slide switch
B10: RCC ON/OFF slide switch
B11: Battery compartment
B8
B10B9
B11
B2
B7
B6B3 B5B1B4
EN
