3.11 Print (KEY=2)
Set “P10 PS”: “RS Prt” is selected for the Serial Printer.
When weighing, press MOD Key to print.
SECTION 4 FUNCTIONS AND PARAMETERS
“F1 CLK”: Date and time setting
When “F1 CLK” is showed, press FUN Key. It will display the time.
Time setting: ZERO Key: shift digit; MOD Key: cancel and esc;
TARE Key: value up; FUN Key: enter and esc;
Select date setting mode by pressing TARE Key. “YY-MM-DD”, “MM-DD-YY” or “DD-MM-YY”
Date setting: Same as time setting.
“F2 SLP”: Sleep function For LED Version
SLP no: Set to “SLP no” means the indicator will never sleep.
SLP 3: Set the time span 3 minutes for the sleep. This sleep mode has two options: “off & dot”, which can be
selected by pressing FUN Key when displaying “SLP 3” . ”off” means cutting off the power and “dot” means only
a dot at the last digit will be displayed. When “dot”, weight changing can wake up the indicator.
SLP 5/10/15: Same as SLP 3.
“F2 BK”: Backlight mode setting For LCD version
Auto mode: The backlight will distinguish when no action is taken during a certain time.
Off mode: The backlight is off all the time.
On mode: The backlight is always on.
“F3 KEY”: MOD Key setting
KEY 1
To set the MOD Key for counting, gross / net weight display switch.
KEY 2
To set the MOD Key for accumulation & print.
KEY 3
To set the MOD Key for holding the weight value.
KEY 4
To set the MOD Key for setting tare value in advance.
KEY 5
To set the MOD Key for animal weighing parameters setting.
“F4 CHK”: Check-weighing setting
Options: BEEP 1/2/3.
“F5 Brt”: Adjust the brightness of LED display. For LED version
Select 1-8 : 8 is most bright
“F5 INP”: Display the internal counts For LCD version .
Used to check the connection of loadcell and working status of ADC circuit.
Press “TARE” to exit.
