Marcy 170620 - Page 8

7
Lead-wire Main Wire Connector
Wrap the lead-wire around Main Wire connector. Pull up the lead-wire from top of Right Console Mast until
the connector on Main Wire is out from the handrail hole as shown in the diagram.
Notes: Secure the connector on Main Wire after pulling out to ensure it will not drop back. Loosen and
dispose the lead-wire.
1
3
4
Step 2
Lead-wire
