Marcy 170620 - Page 9

8
Attach the Right Console Mast (4) to the Base Frame (1) using one M8x3” Allen Bolt (66), two M8x3 ⅜”
Allen Bolts (54), two M8x5/8” Allen Bolts (68), five x Ø ⅜” Lock Washers (87), and five Ø ⅝” Washers (84).
Tighten all Bolts in Step-1 and Step-3.
Step 3
3
4
68
87
84
66
87
84
54
