5
PRE-ASSEMBLY CHECK LIST
PART NO. DESCRIPTION Q’TY
1 Main Frame 1
3 Front Stabilizer w/end caps 1
9 Computer 1
14 Pedal R/ L 2
17 Pedal Support Tube 1
26 Slide Rail 1
28 Rear Stabilizer w/end caps 1
36 Seat 1
