FRONT:
• JAP Medium, Jap 38, Contact 32’ or 35’ shore tires trued to 47mm diameter (inside and outside edges
well rounded off), 6mm wide inside edge additive.
• Silver ‘Medium’ spring
• Zero degrees toe in/out
• 3.2mm ride height
• 5th, central plate screw done up with only very light tension (approx 1.5’ camber)
• 1.0mm castor shims added under front end of wishbone plate.
QUICK SETUP
FRONT:
• UFRA Pink Medium or Contact 32 shore tires trued to around 49mm diameter (edges well rounded again)
and full width additive
• Silver ‘Medium’ springs
• 20,000 – 30,000wt damper oil
• Diff set to medium
• Motor spaced 4mm away from motor pod
• 3.2mm ride height
• Gearing on 1s LiPo / 13.5t motor (HPI Flux) – 54-56mm/rev
THANKS GOES OUT TO JAMES GARRETT, JOHN PARKER & OTHERS. HAPPY RACING!
