The Scale page
The Scale page in P02 1013 shows the current product name (1), the
calculated/selected nominal weight (2), the packing bar (3), and the
weight display (4).
You can use the arrow keys to select the previous or the next product.
2
3
4
1
Figure 3 The P02 1013 application, Scale page.
The Application Page
From the Scale page press to display the Application display, which
gives access to two pages, the Data page and the Debug page.
Use the
DEBUG and DATA keys to switch between pages.
1
2
3
Figure 4 The Application display, Data page.
4
6
5
Packing Scale P02 1013 Application • 3
