seconds, then release it. If the pilot flame goes out, repeat the
operation.
The pilot can be seen and if necessary lit throught the hole in
the floor of the oven.
• Turn the knob to the desired cooking temperature.
Turning off the oven burners
• To switch off the main burner, turn knob to position
.
• To switch off the pilot burner, turn knob to position ●.
Use of electric oven
The oven is equipped with two control knobs and one yellow
pilot light.
The selector knob is marked with the following symbols:
0 not in operation
Top heating (grill) in operation
Bottom heating in operation
Top + bottom heating in operation
The working thermostat knob is marked with the following
symbols:
• off
50 Minimum cooking temperature
100-200 Intermediate cooking temperature
300 Maximum cooking temperature
Turning on the oven
• Turn the selector knob to the desired cooking position.
• Turn the working thermostat knob to the desired cooking
temperature (yellow indicator lights).
Turning off the oven
• Turn the working thermostat knob to position •.
• Turn the selector knob to position "0".
CARE AND MAINTENANCE
• Do not wash the appliance with jets of water.
• Before cleaning the appliance, disconnect from the electric
power supply (if connected).
• Clean stainless steel surfaces daily using water and non-
abrasive detergents. Rinse thoroughly and dry.
• Do not use steel wool pads or chlorine-based products.
• Do not use corrosive substances to clean the floor
underneath the appliance.
• If the appliance is to remain idle for a long period, close the
gas shut-off valve upstream of the appliance and clean
thoroughly.
• The appliance should be inspected and the gas exhaust pipe
cleaned by an authorised service engineer at least twice a
year.
For this purpose we recommend taking out a service contract.
Cleaning the interior of the oven
Daily cleaning of the interior of the oven avoids maintenance
problems in the future.
Use a suitable degreasing spray product (not foaming) for
cleaning even in the “hidden” zones.
• heat the oven to 75 – 80° C.
• spray the degreasing solution throughout the interior of the
oven, on the grilles, the grille supports and the oven floor.
• close the oven door and allow the product to react for about
20-30 minutes.
• open the oven door carefully, paying attention to the eyes
and the skin.
• remove from the oven cavity the grille supports, the grilles
and the floor and wash separately.
• clean and rinse the oven interior with a sponge using tepid
soapy water and/or normal liquid detergents, drying
afterwards.
• Remount the internal parts and dry further by turning on the
heating for a few minutes.
SPARE PARTS LIST
Gas ranges
• Gas tap
• Gas valve
• Cooking hob burner
• Oven burner
• Pilot burner
• Thermocouple of cooking hob and oven
• Ignition electrode
• Piezo igniter
Electric oven
• Working thermostat
• Selector
• Heating element
• Yellow pilot lamp
• Safety thermostat
