Series 5 Digital Force Gauges User’s Guide
24
11 PASSWORDS
Two separate passwords may be set to control access to the Calibration section and to the menu and
other keys. To access the passwords setup screen, select Passwords from the menu. The display
appears as follows:
Select “+ More” for additional options:
11.1 Calibration Password
Select Calibration from the sub-menu. The display appears as follows:
To set the password, select Enabled, then Set Password. Use the UP and DOWN keys to increment and
decrement the value, from 0 to 9999. When the desired value has been selected, press ENTER, then
ESC to exit the sub-menu.
11.2 Menu Key Password
If enabled, every time the MENU key is selected, a password must be provided. Select Menu Key from
the sub-menu. Follow the same procedure as described in the previous sub-section.
11.3 Locking Out Other Keys
Other keys may be locked out individually. Select any combination of keys (UNITS, MODE, ZERO,
DATA, CLEAR, POWER) by pressing ENTER in the Passwords sub-menu. Pressing a locked key will
prompt the message “KEY PROTECTED” instead of performing the key’s function.
11.4 Password Prompts
If passwords have been enabled, the following will be displayed when pressing the MENU key or
accessing the Calibration section:
PASSWORDS
DATA Key
CLEAR Key
POWER Key
PASSWORDS
Calibration
MENU Key
UNITS Key
MODE Key
ZERO Key
+ More
CALIBRATION PASSWORD
* Disabled
Enabled
Set Password
(0000 – 9999)
5000
