23
3 aes/ebu electrical digital inputs (#1 & #2)
These inputs accept the digital audio signal (DAS) via cables
equipped with XLR-type connectors from digital sources such as a
compact disc transport, DVD transport, laser disc transport, digi-
tal audio tape transport, or digital broadcast receiver.
These inputs conform to the AES/EBU digital interconnection stan-
dard, which calls for a 110Ω transmission of the DAS. Use a digital
interconnecting cable specifically designed for the 110Ω
AES/EBU standard, such as Madrigal MDC-1 cable, when using
these inputs. The pin assignments for the AES/EBU digital intercon-
nection standard are shown below.
PUSH
21
3
Pin 1: chassis ground
Pin 2: non-inverted digital
Pin 3: inverted digital
Connector ground lug: chassis ground
4 ST optical digital input (#3)
This input accepts the digital audio signal (DAS), via optical cable
equipped with the ST-type optical connector (sometimes called
“AT&T”) from digital sources such as a compact disc transport, la-
ser disc transport, digital audio tape transport, digital broadcast
receiver.
5 BNC S/PDIF electrical digital input (#4)
This input accepts the digital audio signal (DAS) via cables
equipped with BNC-type connectors from digital sources such as a
compact disc transport, laser disc transport, digital audio tape
transport, digital broadcast receiver.
This input conforms to the Sony/Philips Digital Interface Stan-
dard (S/PDIF), which calls for a 75Ω transmission of the DAS. Use a
digital interconnecting cable specifically designed for the 75Ω S/
PDIF standard, such as Madrigal MDC-2 cable, when using this in-
put.
6 RCA S/PDIF electrical digital input (#5)
This input accepts the digital audio signal (DAS) via cables
equipped with RCA-type connectors from digital sources such as a
compact disc transport, laser disc transport, digital audio tape
transport, digital broadcast receiver.
