519 AUDIO PLAYER / OWNER’S MANUAL
ENGLISH
MARK LEVINSON N
0
519 SPECIFICATIONS
1. Digital input sample rates and bit depth: PCM: 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz/up to
32-bit; DSD: Native, single- and double-speed
2. Analog audio connectors: 1 pair single-ended line outputs (RCA); 1 pair balanced line outputs
(XLR); 1 headphone output (1/4-inch TS phone)
3. Digital audio connectors: 1 balanced AES/EBU input (XLR); 2 coaxial S/PDIF inputs (RCA); 2
optical inputs (Toslink); 1 asynchronous USB input (USB-B); 1 balanced
AES/EBU output (XLR); 1 coaxial S/PDIF output (RCA); 1 optical output
(Toslink)
4. Control connectors: 1 RS-232 port (RJ-11 connector); 1 IR input (1/8” TS phone); 2
programmable 12V DC trigger outputs (1/8” TS phone), 100mA
maximum; 1 programmable 12 DC trigger input (1/8” TS phone); 1
gigabit Ethernet connector (RJ- 45 connector); 2 USB-A (mass storage,
firmware update, and configuration I/O); 1 Micro USB (device discovery)
5. Wireless: Wi-Fi 802.11b/g/n, Bluetooth with aptX codec Bluetooth range: 15m/50ft
Bluetooth® transmitter frequency range: 2402 − 2480MHz
Bluetooth® transmitter power: <20dBm
Bluetooth® transmitter modulation: GFSK, pi/4 DQPSK, 8DPSK
5G Wi-Fi transmitter frequency range: 5.15~5.35GHz,
5.470~5.725GHz,5.725~5.825GHz
5G Wi-Fi transmitter power: <20dBm (EIRP)
5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM, 64QAM, 256QAM
5G Wi-Fi network compatibility: IEEE 802.11 n
2.4G Wi-Fi transmitter frequency range: 2412 – 2472MHz (2.4GHz ISM
Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: <20dBm (EIRP)
2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
2.4G Wi-Fi network compatibility: IEEE 802.11b/g/n
6. Mains voltage: 100V AC, 115V AC, or 230V AC (set at the factory for the region for which
the unit is intended)
7. Power consumption:
WITHOUT WITH
HEADPHONE HEADPHONE
On: 39W 50W
Normal Standby: 33W 46W
Power Save Standby: 10W 10W
Green Standby (Default): 0.4W 0.4W
8. Operating temperature range: 50°F (10°C) … 104°F (40°C)
9. Unit dimensions: Height: 5.75” [146mm]
Width: 17.25” [438mm]
Depth: 16” [406mm]
Weight: 36 lbs. [16.4kg]
With Packaging: Height: 17” [432mm]
Width: 26” [660mm]
Depth: 26” [660mm]
Weight: 56 lbs [25.5kg]
SPECIFICATIONS
