MarkBass SD800 - Front Panel Controls Overview; Input and Gain Controls; Equalization and Filter Controls; Master Volume and Power Switch

03
16
17 18 19
20 21 22 23
24
PRE EQ
POST EQ
2. SA450 / SD800 / SD1200 FRONT PANEL
1 UNBALANCED 1/4” JACK INPUT
2 GAIN
3 CLIP LED
4 LINE OUT LEVEL KNOB
5 LOW EQUALIZATION LEVEL KNOB
6 MID LOW EQUALIZATION LEVEL CONTROL KNOB
7 MID LOW EQUALIZATION FREQUENCY CONTROL KNOB
8 MID HIGH EQUALIZATION LEVEL CONTROL KNOB
9 MID HIGH EQUALIZATION FREQUENCY CONTROL KNOB
10 HIGH EQUALIZATION LEVEL CONTROL KNOB
11 VLE FILTER LEVEL CONTROL KNOB
12 VPF FILTER LEVEL CONTROL KNOB
13 POWER ON LED
14 MASTER VOLUME LEVEL KNOB
15 MAIN ON/OFF SWITCH
3.
SA450 / SD800 / SD1200 REAR PANEL
16 AC POWER SOCKET
17 SPEAKER OUT: SPEAKON / 1/4” COMBO JACK (SA450, SD800)
SPEAKON (SD1200) -
please use only
speakon-speakon power
cable to ensure your safety.
18 SPEAKER OUT: SPEAKON / 1/4” COMBO JACK (SA450, SD800)
SPEAKON (SD1200) -
please use only
speakon-speakon power
cable to ensure your safety.
19 PRE/POST EQUALIZATION CONTROL SWITCH
20 TUNER OUT 1/4” JACK
21 RETURN EFFECT 1/4” JACK
22 SEND EFFECT 1/4” JACK
23 LINE OUT XLR
24 GROUND LIFT CONTROL SWITCH
