Markilux 710 User Manual

markilux.com
1 Cover cassette 6 the fixture brackets
2 Hand crank (for manual operation) 7 gas piston
3 Guide track 8 Drop arm bracket
4 Angled guide rail 9 front profile
5 Cover
markilux important notes
markilux operating instructions
Page
1. Reading the instructions 7
2. Awning with manual operation 7
2.1 Standard manual operation - outside operation 7
2.2 Awnings with interior operation (markilux 710 / 810, 720 / 820, 730 / 830, 740 / 840, 750 / 850) 8
2.3 Direction of rotation during retraction 8
3. Awning with motorised operation 8
4. Modification or retrofitting 9
5. Safety note 9
6. Awning with extendable standpipe (markilux 730 / 830) 9
Table of contents
1
2
6
7
5
8
9
1
2
5
7
4
8
9
markilux 730 / 830 markilux 740 / 840
730 830
Attention: When retracting drop-arm awnings, there is danger of crushing between the drop arms and the guide rails.
It has to be ensured that there are no body parts in this range. It is important to observe in particular point 8 in the "Safety
instructions" and point 12 of the chapter "Important notes".
