Marklin Digital 60906 - Page 19

19
CV Meaning Values Default
Note
1 Main Address 1 – 127 3
If CV 29 / Bit 5 = 0
2
PoM
Minimum Speed (Vmin) 0 – 255 15
3
PoM
Acceleration Delay (AV) 0 – 255 16
4
PoM
Braking Delay (BV) 0 – 255 20
5
PoM
Maximum Speed (Vmax) 0 – 255 240
8 Decoder Reset (default or factory setting) 8 131
13
PoM
Functions F1 – F8 with alternative Track Signal 0 – 255
0
14
PoM
Functions FL, F9 – F15 with alternative Track Signal 0 – 255 1
17 Advanced Address, higher value Byte 192 – 231 192
CV29 / Bit 5 = 1
18 Advanced Address, lower value Byte 0 – 255 128
19 M.U. Address 0 – 255 0
1 – 127 = M.U. Address
+128 = Reverse polarity of direction when
m.u. address
21
PoM
Functions F1 – F8 when M.U. 0 – 255 0
22
PoM
Functions FL, F9 – F15 when M.U. 0 – 255 0
27
PoM
Braking Mode:
Bit 4 : DC, Polarity against the direction
Bit 5 : DC, DC, Polarity with the direction
Bit 6 - 7 : Always 0
0 / 16
0 / 32
0
48
29
PoM
Bit 0 : Reversing Locomotive Direction Behavior
Bit 1 : Select Speed Levels 14 or 28/128
Bit 2 : Turn Analog Operation on/off
Bit 5 : Select Short / Long Address
0 / 1
0 / 2
0 / 4
0 / 32
6
CV Table for DCC
