42
CV
Explanation
Values
Default
Notes
29
Configuration:
Bit 0: Reverse the locomotive’s direction properties
0 = normal direction
1 = invert direction
Bit 1: number of speed levels
half levels 14 or 27
0 = 14 speed levels
1 = 27 speed levels / half levels
Bit 2: turn analog operation on/off
0 = analog off, 1 = analog on
0 - 7
6
The direction properties refer to the direc-
tion of travel and the lights.
The number of speed levels and half levels
depend on the locomotive controller.
Only digital operation or also conventional
operation. Flipping back and forth between
the modes is possible during operation.
49
Expanded configuration:
Bit 0: number of addresses, LSB
Bit 1: number of addresses, MSB
Bit 2: automatic consecutive addressing
(on / 1=off)
0 - 7
5
0 = one | 1 = two | 0 = three | 1 = four
0 Add. | 0 Add. | 1 Add. | 1 Add.
0 = auto. sequence on / 1 = auto. sequence off
50
Alternative formats:
Bit 0: analog AC off = 0 / analog AC one = 1
Bit 1: analog DC off = 0 / analog DC on = 1
Bit 2: DCC off = 0 / DCC on = 1
Bit 3: mfx off = 0 / mfx on = 1
0 - 15
0 / 1
0 / 2
0 / 4
0 / 8
15
Note:
fx (Motorola) cannot deactivate itself
51
Bit 0: Motor inverted 1= on, 0 off
Bit 1: Light inverted 1= on, 0 off
Bit 2: Track inverted 1= on, 0 off
Bit 3: Aux 3 (1= logical, 0= amplified output)
Bit 4: Aux 4 (1= logical, 0= amplified output)
0 / 1
0 / 2
0 / 4
0 / 8
0 / 16
0
The values of the required settings must be
added up.
CV Table for fx (MM)
* () = 6021 Control Unit {} = the values entered are multiplied times “x” (factor).
