CV Table for DCC
CV
Explanation
Values
Default Notes
31
PoM
Index high Byte 16 16
This is required for advanced settings,
such as CV 300 – 328.
32
PoM
Index low Byte 0 0
50
PoM
Alternative formats:
Bit 0 : Analog AC off = 0 / Analog AC on = 1
Bit 1 : Analog DC off = 0 / Analog DC on = 1
Bit 2 : fx (MM) off = 0 / fx (MM) on = 1
Bit 3 : mfx off = 0 / mfx on = 1
0 - 15
0 / 1
0 / 2
0 / 4
0 / 8
15
Note:
DCC cannot deactivate itself.
51
PoM
Bit 0: Motor inverted 1= on, 0 off
Bit 1: Light inverted 1= on, 0 off
Bit 2: Track inverted 1= on, 0 off
Bit 3: Aux 3 (1= logical, 0= amplified output)
Bit 4: Aux 4 (1= logical, 0= amplified output)
0 / 1
0 / 2
0 / 4
0 / 8
0 / 16
0
The values of the required settings must
be added up.
52
PoM
Motor type ... (Bit 0-4)
... Auxiliary – function outputs 5 and 6
... Motor – Softdrive Sine
... Motor – without feedback control
... Motor – high-efciency C90
... Motor – bell armature
... Motor – direct current DC soft
... Motor – direct current DC hard
... Motor – direct current DC 1 Gauge
0 - 7
0
1
2
3
4
5
6
7
5
Selection of a motor type for additional
settings for motor feedback control
or
Selection of additional function outputs
on an H0 decoder. See extra table for how
motor outputs work as additional auxiliary
functions.
53
PoM
Motor feedback control – feedback control
reference
0 - 255
40
Absolute Vmax for motor characteristic
54
PoM
Motor feedback control – feedback control parameter K 0 - 255
80
Feedback control portion K
55
PoM
Motor feedback control – feedback control
parameter I
0 - 255
60
Feedback control portion I
PoM must be supported by the locomotive controller / central controller.
