6
Preparingthewireandmakingconnectionswithit
Payparticularattentionwhendoingthis
Connecttheredthirdrailwirefromthefeedertracktothe
redterminalclip(“B”=trackpower)onthe32WTransfor-
mer.Thenconnectthebrowngroundreturnwirefromthe
feedertracktothebrownterminalclip(“0”=ground)onthe
32WTransformer
 Figure1,page30.
Important!
Thefeederwiresfromthelayouttothetransformer
mustneverbepluggedintoahouseholdpower
outlet.Makesureyourchildrenareawareofthis
danger!
2. Connecting the Transformer
Makesurethatthepowercordsforallofthetransformers
usedwithyourlayoutaredisconnectedfromthehousehold
currentbeforeconnectingatransformertothelayout!
Possible Uses for the Transformer
TrainoperationwithACcurrentforMärklinH0or1.
Conventionalhookupofturnoutsandsignalmechanisms.
Conventionalhookupofmodelrailroadlighting.
FeederTracks
KTrack:2290+74041
FeederWireSets
C-Track:74041
FeederWireSets
1-Track:74044
5
4
8 mm
1
2 3
!
