DOOR/WINDOW SENSOR DS90
1. Transmitter part.
2. Magnet contact.
3. Control Indicator - Lights up when a signal is
transmitted.
4. Screw for opening the sensor.
5. Switch for entry delays.
6. Connection for extra wired contact.
7. Battery compartment.
8. Screw holes for mounting the sensor.
9. Tamper contact.
