Marmitek Split TS14 - Left; Right; Back; Connection Diagram

© MARMITEK
6
Active Speak ers
Blu-ray player
Active Speak ers
POW ER
6.2 Left
1. Optical In: Connect your
audio source to these
inputs with an optical
(Toslink) digital audio
cable (not supplied).
6.3 Right
1. Optical Out: Connect
your audio amplifier or
powered speakers to
these outputs using an
optical (Toslink) digital
audio cable (not
supplied).
6.4 Back
1. DC 5V: Connect the
power adapter (included)
and plug it into the
mains.
7 Connection
diagram
OPTICAL IN
1
OPTICAL OUT
1
DC 5V
1
