The control panel
charging complete
charging in progress
switch button
charging socket
GB
22
Troubleshooting:
Symptoms:
Reason:
Solution:
Sprayer does not
work
Swich button off
Press the switch button on the
control panel
Discharged battery
Charge the battery ("process" on the
control panel will show)
Despite charging
the sprayer, the
control panel does
not light up
Charger does not work
Buy new charger
Defect in control panel
Contact Marolex service
Feeding valve R020j
leaking
Loose hose nut R80e or
damaged gasket R47c
Tighten the nut or replace the gasket
R47c (found in repair kit Z08j or
washers kit Z08u)
Freezing water ruptured
handle or valve.
Replace the valve & handle – R020j
Damaged valves cylinder
top gasket (it wasn’t
lubricated periodically)
Replace the piston with the o-rings
(found in kits Z08j and Z08z) or even
the entire R020j valve
Lost seal R47c or
unscrewed lance
Insert the seal R47c or screw the
Blocked trigger
button R44
Trigger button is in
continuous work position
Unblock the trigger button by
pressing it and moving backward
The valve’s piston is
seized
Replace the valve’s piston (included in
kits Z08j, Z08z) or replace the entire
handle with valve R020j.
Weak spraying
action although the
pressure in the tank
is high
R40 filter dirty
Unscrew the hose, remove the
R40 filter and clean it or replace
with a new one (found in kits
Z08j, Z08b,R40)
Clogged nozzle in the
lance
Unscrew the nozzle cap R115, then
the nozzle nut R64, take out the
nozzle core R114 and rinse all parts
under running water; lubricate the o-
ring on the nozzle core and assemble
