h. Connect the windlass, control unit and power source using electric
cable indicated below. Keep the power supply cable as short as
possible. Too thin and/or too much length of electric cable will
reduce the performance of the windlass or cause the circuit breaker
to work incorrectly.
i. Using foot switches or multiple control switches, a “Remote Control
Box (reversing solenoid) 7-1556” is necessary.
For better performance, we recommend to use “Remote Control Box”
instead of “7-1558” for the 7-1553 & 7-1554 windlasses.
For safety reasons, DO NOT connect the power
source direct to the battery. Please connect the
power cable to the main power switch on your
