1 GETTING STARTED
There are three Nemo versions with a different rear panel; one of them,
with DigiCrown box connectors, it is designed for digital probe devices and
Marposs DigiNet products (see F
IGURE 1). The second one is designed for
input devices using USB connections and Marposs EasyBox products (see
F
IGURE 2). The last one is designed for input devices using USB connections
like Red Crown2 USB (see F
IGURE 3).
FIGURE 1
MAX. 3
MODULES
MAX. 8
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
FIGURE 2
NO
MAX. 8
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
FIGURE 3
NO
MAX. 8
DEVICES
MAX. 8
DEVICES
MAX. 8
DEVICES
MAX. 2
DEVICES
