EN
36
TECHNICAL DATA
Rated voltage 12 V DC
Output 4 x 40 W
Speaker impedance 4 Ohm
Maximum output level 2 V rms
Frequency range 20 Hz – 20 kHz
Signal/noise ratio 65 dB
Channel separation 55 dB
Touch screen 6.2"
RCA connector for reversing camera Yes
Bluetooth Yes
ISO Yes
MP3 Yes
MP4 Yes
Support for HD 2.5" (FAT) Yes
WMW Yes
FLAC EQ Yes
RM Yes
RMVB Yes
AUX (3.5 mm) Yes
SD outlet Yes
USB port Yes
Built-in microphone Yes
Remote control Included
FM radio
Frequency range 87.5 – 108.0 MHz
AM radio
Frequency range 522 – 1620 kHz
DESCRIPTION
1. Main unit and front panel (incl. holder)
2. Remote control
3. Frame
4. ISO standard connectors
5. Removal tool (2)
6. Hex screw
7. Screws (M4 x 8 mm)
8. Instructions
leakage and corrosion. Follow the
instructions below to ensure that the
remote control works properly.
– Insert the batteries with the correct
polarity.
– Do not attempt to charge the
batteries.
– Do not expose the batteries to heat.
– Do not short circuit the batteries.
– Never attempt to open the batteries.
– Do not burn the batteries.
– Do not leave spent batteries in the
remote control.
– Do not mix dierent types of
batteries, or old and new batteries.
– Remove the batteries from the
remote control if it is not going to be
used for some time (batteries can
leak).
– If electrolyte has leaked from the
batteries the remote control must be
cleaned by an authorised service
centre or other qualied personnel.
Symbols
Read the instructions.
Approved in accordance with
the relevant EU directives.
Recycle as electrical waste.
