DIN REAR-MOUNT (Method B)
If your vehicle is a Nissan, Toyota, follow these
mounting instructions.
Use the screw holes marked T (Toyota), N (Nissan)
located on both sides of the unit to fasten the uni
t to
the factory radio mounting brackets supplied with
your vehicle.
Dashboard or Console
Screw
Factory Radio
Mounting Bracket
Side View showing
Screw Holes marked
T, N
Screw
To fasten the unit to the factory radio mounting
brackets.
Align the screw holes on the bracket with the screw
holes on the unit, and then tighten the screws
(5x5mm) on each side.
Note: the outer trim ring, sleeve and the metal str
ap
are not used for method B installation.
INSTALLATION
9
