TECHNICAL INFORMATION
SOUND SPECIFICATION
• MAINS INPUT VOLTAGE: 100-240V~ /200W
• NOMINAL RATING: 100-240V~
• ABSOLUTE MIN/MAX: 90-264V~
• MAINS FREQUENCY: 50-60Hz
• MAX PEAK POWER CONSUMPTION: 200W
TECHNICAL INFORMATION
• ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• DIGITAL CLASS D AMPLIFIER: 2X20W+1X40W
• ¾” DOME TWEETERS: 2X
• 5 ¼” WOOFER: 1X
• BASS AND TREBLE TONE CONTROLS
• FREQUENCY RESPONSE: 45- 22.000HZ +-3DB
• CROSSOVER FREQUENCY: 2500HZ
• CONNECTIVITY:
- BLUETOOTH: STANDARD V4.0 + EDR aptX® CODEC
- INPUT 1 - 3.5MM: 1X
- INPUT 2 - RCA: 1X
- OPTICAL INPUT: 1X
• TWO STANDBY MODES: POWERSAVER MODE (0,43W)
AND STANDARD MODE (8,7W)
• MAX POWER OUTPUT: 80W RMS
• WEIGHT: 5.10KG
• SIZE: 350 X 185 X 185MM
NOTE: THE FRONT FRET IS NOT REMOVEABLE. THIS ILLUSTRATION INTENDS TO
SHOW THE INTERNAL SPEAKER LAYOUT. DO NOT ATTEMPT TO REMOVE THE
FRONT FRET FOR RISK OF DAMAGING YOUR ACTIVE LOUDSPEAKER.
