CV620-IP / CV620-NDI RS-232 Command Set
www.marshall-usa.com3 4
5. Command execution cancel
Cancel Packet Note
Cancel
8X 2Y FF Y = socket number
X = 1 to 7==>camera address, Y = socket number,
Y=1 to 2
6. Network Change
Packet Note
Address
88 30 01 FF Always broadcasted
Network Change
X0 38 FF
X = 9 to F==>camera address + 8
7. IF_Clear
Command Reply Packet Note
IF_Clear
8X 01 00 01 FF X0 50 FF
IF_Clear (broadcast)
88 01 00 01 FF 88 01 00 01 FF
X = 1 to 7==>camera address (For inquiry packet)
X = 9 to F==>camera address +8 (For reply packet)
8. Zoom Focus Position Table
Zoom Position
Wide end Optical Digital
Tele end Tele end
0x0000 to 0x4000 NULL
Focus Position
Far end Near end
0x000 to 0x3C3 pqrs:0x000 ~ 0x3C3
9. Optical Zoom Position Table
Optical Zoom Ratio pqrs
x1 0x0000
x2 0x1844
x3 0x22BF
x4 0x28F0
x5 0x2D3B
x6 0x3087
x7 0x331F
x8 0x3552
x9 0x371E
x10 0x38B7
x11 0x3A03
x12 0x3B4F
x13 0x3C4F
x14 0x3D1B
x15 0x3DE8
x16 0x3E81
x17 0x3F01
x18 0x3F67
x19 0x3FB4
x20 0x4000
10. Digital Zoom Position Table
Digital Zoom Ratio pq
x1 NULL
x2 NULL
x3 NULL
x4 NULL
x5 NULL
x6 NULL
x7 NULL
x8 NULL
x9 NULL
x10 NULL
x11 NULL
x12 NULL
