7. Hardware Installation
1. Connect display, recorder, etc. to SDI Output of VSW-2000
2. Connect the SDI input sources to the inputs of VSW-2000.
3. Screw on the 5V power supply unit to the locking power jack.
4. Use IR remote, RS-232, or front panel push button to switch between input channels.
8. Connection Diagram
SDI Camera
Marshall CV620 / SDI Camera
Marshall CV342 / SDI Camera
Set Box
SDI Cable
Marshall
SDI Monitor
SDI Cable
VSW-2000 Rear View
