Marson MT1095 - Product Overview and Specifications; Out of Box Contents; Device Introduction; Technical Specifications

OUT OF THE BOX
Mini Barcode Reader CD
Quick Guide
USB Extension Cable
(Optional)
Scanner Tools
Mini Barcode Reader
Quick Guide
- 3 -
INTRODUCTION
SPECIFICATIONS
Trigger
Beeper
Exit Window
USB Connector
Protective Cover
Light source 625nm visible red LED
Scan rate 240 scans/sec
Sensor Linear CMOS sensor
Resolution 5mil/ 0.127mm
PCS 30%
Housing Plastic(Polycarbonate)
Interface USB
Voltage 5 VDC ± 5%
Current < 115 mA(Working); < 60 mA(Standby)
Operating Temp 0 to 50˚C (32˚F to 122˚F)
Storage Temp -20 to 60˚C (-4˚F to 140˚F)
Symbologies All major 1D barcodes incl. GS1 Databar
- 4 -
