5-22
OTHER CONTROLS AND EQUIPMENT
56RH0-74E
Automatic heating and
air conditioning system
(climate control)
Description of cont
rols
56RH00533
(8)
(3)
(7)
(6)
(5)
(1)
(9)
(2)
(4)
EXAMPL
E
(1)
T
emperature selector
(2)
Blower speed selecto
r
(3)
Air intake selector
(4)
Air flow selector
(5)
Defrost switch
(6)
Air conditioning switch
(7)
“OFF” switch
(8)
“AUTO” switch
(9)
Display
