1. Tighten the strap
.nesool ot drawpu elkcub parts tfiL.drawnwod parts eht lluP
2. Loosen the strap
The adjustment of knapsack strap
3. Handling and operating method
Assembly of nozzle and assembly of belly band
Assembly of nozzle
After confirming the existence of packing, securely tighten nozzle pipe to grip, and wide nozzle to nozzle
pipe. Tighten the screw securly after confirming the packing to make ensure there is no water leakage.
Over-tightening will cause extrusion or break the packing. Correct tightening pressure is important.
Wide nozzle Nozzle pipe Grip
Ball cock Spraying hose assembly
Connect opposite side of hose to
discharge opening of the spraying
machine.
Discharge opening
