6BARM BEVERAGE AND WINE REFRIGERATOR FEATURES
Loading Tips and Suggesons
The wine rack pull-out shelf holds eight (8) boles. See Figure 4
and Figure 6 for typical wine bole orientaon. The wine rack is
located at the boom of the cabinet just above the xed wooden
bole cradle which will store 6 boles of wine. The glass and
metal shelves and xed posion wire rack are for general bever-
age storage, such as beer and so drinks. The glass shelf also
acts as a zone separator to create a warmer zone (5° - 8°F) for
wine storage. To cool your wine to the same temperature as set
point, the glass can be removed and if necessary replaced with
a second metal shelf. Opened wine boles and tall beverage
containers may be stored on the black metal shelf closest to the
cabinet top, on the right side where there is clearance for the
boles and/or containers to stand upright.
(See Figure 5).
The wooden, boom bole cradle may be removed for stor-
ing “jug” wines. Just remove the two (2) screws that secure the
cradle to the cabinet oor.
You may store magnums and other large boles on any of the
racks (except for the top rack) by removing the rack directly
above them. Posion white wines on the middle or lower racks
and red wines on the upper racks (see Figure 6).
The boles on the top rack directly under the light will be
exposed to a slightly higher temperature when the light is on.
Posion your wines accordingly and REMEMBER TO TURN OFF
THE LIGHT WHEN IT IS NO LONGER NEEDED.
Keep wines that you plan to use for everyday drinking and enter-
taining on the front half of the racks where labels are completely
visible. Place wines for aging or longer term storing in the rear.
Pull-out Rack
The pull-out wine rack may be pulled out approximately seven
and a half (7.5) inches to facilitate adding or removing boles.
Do NOT lean on or press down heavily on the wine shelf. Doing
so may damage the shelf and the wine boles stored on it. Pull
the wine rack out gently and carefully to minimize unseling
your wine collecon.
Single Bole Racks
Since boles are not stacked on top of each other, you can easily
view and access your inventory without disturbing other boles
(see Figure 6).
Figure 6
7
Front Boles (Necks Facing Rear)
Rear Boles (Necks Facing Front)
Figure 4
Figure 5
Staonary
shelf
Perforated
metal shelf
Glass shelf
Wine shelf
Wine cradle
Tall bole
storage
