Mase Generators IS 7.6 User Manual

Fig. 17
GEN.
LOAD
MAIN
Fig. 16
1
6
WIRING DIAGRAM REFERENCES
1 - Hour Meter
2 - Circuit breaker
3 - Isolator
4 - Power terminal board
5 - Capacitors
6 - Stator
7 - Rotor
8 - Alternator
9 - Thermal switch
10 - START / STOP-Preheating button
11 - Engine protection module
12 - Terminal board
13 - Connector for remote control panel
14 - Fuel level gauge
15 - Oil pressure gauge
16 - Water temperature gauge
17 - High water temperature sensor
18 - High coolant temperature sensor
19 - Oil pressure switch
20 - Battery charger alternator
21 - Fuel pump
22 - Stop elestromagnet
23 - Starter motor
24 - Battery connection terminals
25 - Preheating glow plugs
26 - Fuses
27 - Preheating relay
28 - Remote control panel connection cable
29 - START / STOP-Preheating button
30 - Oil pressure gauge instrument
31 - Coolant temperature gauge instrument
32 - Remote control kit with instrumentals
33 - Remote control kit
