6
SETTING UP THE LOG SPLITTER
It may be helpful to familiarize yourself with the controls and features of your KINETIC LOG SPLITTER as shown in Figure 1 before beginning these
procedures. If you have any questions at all, please feel free to contact us your local dealer.
KINETIC LOG SPLITTER CONTROLS AND FEATURES
Fig.1
Safety Level
Engagement Handle
Belt Guard
Cradle
Frame stand
Handle
Splitting Wedge
Ram
Flywheel
Belt
MODEL SK-E5T SK-E8T
Motor 1500W,240V~50Hz 1600W, 240V-50Hz
Max Splitting force 5ton 8ton
Max splitting length 400mm 520mm
Max splitting dia. 280mm 350mm
RPM 400 450
Cycle time 2seconds 2seconds
New weight 90kgs 110kgs
NOTE
* The 5 & 8 ton splitting force relate to these being an equivalent to hydraulic log splitters.
* The diameter listed is indicative of the maximum suggested size. A small log can be difficult to split when it contains knots or a particularly tough fiber.
On the other hand, it may not be difficult to split logs with regular fibers even if its diameter exceeds the maximum indicated above.
* Hard wood requires more force to split even if the diameter is less than the mazimum size.
* Do not force the log splitter if you are experiencing any of the above conditions
* These log splitters are designed to operate on 240 volt AC power, if you wish to use a generator, it must have suitable start up and continuous power
supply. Consult a professional before purchasing or hiring a generator.
