Attachment Lift Control Lever
When using the mower deck, lift the deck off the ground
while transporting to and from the job site. DO NOT cut
with the mower in the raised, transport position.
The attachment lift control lever raises and lowers
attachments that utilize the tractor’s manual lift linkage.
To lower an attachment: pull the lever back slightly, then
push the lever forward. To raise an attachment: pull the
lever back and lock it in the raised position.
The attachment lift lever has three positions The back
position is for transporting to and from the work site. The
middle notch provides maximum traction when mowing
on hills. The forward position provides the most down-
ward pressure giving the best cut.
Mower Height of Cut Adjustment
The cutting height adjustment knob controls the mower
cutting height. The cutting height is infinitely adjustable
between 1” (2,5 cm) and 3-3/4” (9,5 cm).
Headlights
The headlight switch turns the tractor headlights on and
off.
Brake Pedal
Depressing the brake pedal applies the tractor brake.
Ground Speed Pedals
The tractor’s forward ground speed is controlled by the
forward ground speed control pedal. The tractor’s
reverse ground speed is controlled by the reverse
ground speed control pedal.
Depressing either pedal will increase ground speed.
Note that the further down the pedal is depressed, the
faster the tractor will travel.
PTO Switch
The PTO (Power Take-Off) switch engages and disen-
gages attachments that use the PTO. To engage the
PTO, pull UP on the switch. Push DOWN to disengage.
Note that the operator must be seated firmly in the trac-
tor seat for the PTO to function.
11
Features & Controls
Ignition Switch
The ignition switch starts and stops the engine, it has
three positions:
OFF Stops the engine and shuts off the
electrical system.
RUN Allows the engine to run and powers the
electrical system.
START Cranks the engine for starting.
NOTE: Never leave the ignition switch in the RUN posi-
tion with the engine stopped–this drains the battery.
Parking Brake
The parking brake knob is used to lock the parking brake
when the tractor is stopped. Fully depressing the brake
pedal and pulling up on the knob engages the parking
brake. Refer to page 10 for a full explanation of parking
brake functions.
Seat Adjustment Lever
The seat can be adjusted forward and back. Move the
lever, position the seat as desired, and release the lever
to lock the seat into position.
Fuel Tank & Gauge
The fuel gauge is located in the filler cap and indicates
the amount of fuel in the tank. To refuel the unit, remove
the fill cap and fill to just below the filler neck.
Transmission Release Valve Lever
The transmission release valve lever deactivates the
transmission so that the tractor can be pushed by hand.
See PUSHING THE TRACTOR BY HAND for opera-
tional information.
