36
Specifications, Parts, &
Accessories
Model:
Mfg. No.:
Your Name:
Address:
City, State, Zip:
Visa/Mastercard No.:
Card Expiration Date:
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors.
ENGINE:
15 HP*
Make Briggs & Stratton
Model OHV 31F777
Horsepower 15 @ 3600 rpm
Displacement 30.6 Cu. in (502 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 230 CCA
Oil Capacity 1.5 Quarts (1,4 L)
16 HP*
Make Briggs & Stratton
Model Vanguard
Horsepower 16 @ 3600 rpm
Displacement 29.3 Cu. in (480 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 230 CCA
Oil Capacity 1.75 Quarts (1,7 L)
17 HP*
Make Briggs & Stratton
Model OHV 31F777
Horsepower 17 @ 3600 rpm
Displacement 30.6 Cu. in (502 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 230 CCA
Oil Capacity 1.5 Quarts (1,4 L)
CHASSIS:
Fuel Tank Cap. Capacity: 5 Gallons (18,9 L)
Rear Wheels Tire Size: 15 x 6.00-6
Inflation Pressure: 12-15 psi (,8-1 bar)
Front Wheels Tire Size: 18 x 8.50-8
Inflation Press.: 15 psi (1 bar)
TRANSMISSION:
K46
Type Hydrostatic Tuff Torq K46
Hydraulic Fluid 10w 30 Premium Engine Oil
Capacity 2.6 qt (2,5 L)
Speeds Forward: 4.1 MPH (6,6 km/h)
@ 3400 rpm Reverse: 2,6 MPH (4,2 km/h)
Continuous Torque 215 ft. lbs. (291 N.m.)
Output
Drawbar Rating 440 lbs. (200 Kg)
Maximum Weight 584 lbs. (265 Kg)
on Axle
DIMENSIONS
Overall Length 83” (210 cm)
Overall Width 48” (122 cm)
Height 49” (125 cm)
Weight (approx.)
Lancer / 4400 Series Tractor
Tractor 525 lbs. (238 kg)
44” Mower Deck 107 lbs. (49 kg)
40” Mower Deck 107 lbs. (49 kg)
REPLACEMENT PARTS
Replacement parts are available from your authorized
dealer. Always use genuine Simplicity Service Parts.
TECHNICAL MANUALS
Additional copies of this manual are available, as well as
fully illustrated parts lists. These manuals show all of the
product’s components in exploded views (3D illustrations
which show the relationship of parts and how they go
together) as well as part numbers and quantities used.
Important assembly notes and torque values are also
included.
For applicable manuals currently available for your
model, contact our Customer Publications Department at
262-284-8519. Have the information listed in the box
below available when phoning in your request.
Technical manuals can be downloaded from
www.simplicitymfg.com
Engine Oil
Touch-Up Paint
Grease Gun Kit
8 oz. Grease Tube
Tire Sealant
Degrimer/Degreaser
Gas Stabilizer
MAINTENANCE ITEMS
Many convenient and helpful service and maintenance
items are available from your authorized dealer. Some
of these items include:
