Massive DSP-1 - 页 4

AMPLIFIER POWER&
PANEL LAYOUT
USB connection port
between DSP and PC
Proformance modes
selection.
ACC mode and high level
mode exchange button.
Sources signals indicator light.
High level input
(auxiliary input)
High level output
(speaker output)
Front Right Front Left
Rear Left Rear Right
High level input
(speaker input)
Rear Right Rear Left
Front Left Front Right
Power supply cortrol
+ 12V
GND
Output control
