Mastech HY3010E - Technical Parameters; Input Voltage Range

- -
1
DC POWER SUPPLY
BRIEF INTRODUCTION:
The HYXXXXE series Switching DC power supply are very stable, DC power supplies allowing
continuous adjustment of both the output voltage and output current levels.
MODELS:
MODEL HY3010E HY3020E HY3030E HY3050E HY5005E HY5010E HY5020E HY10010E
Regulated
Output
Voltage
0~30V 0~30V 0~30V 0~30V 0~50V 0~50V 0~50V 0~100V
Regulated
Output
Current
0~10A 0~20A 0~30A 0~50A 0~5A 0~10A 0~20A 0~10A
Display Double LED Double LED Double LED Double LED Double LED Double LED Double LED Double LED
Ripple and
Noises
≤0.5mVrms ≤1.0mVrms ≤3.0mVrms ≤3.0mVrms ≤0.5mVrms ≤1.0mVrms ≤3.0mVrms ≤10mVrms
1 TECHNICAL PARAMETER
1.1 Input voltage : 104~127V AC (60Hz), 207~253V AC (50Hz)
