（10）Key of MAX/MIN/AVG
It is used to switch between the measurement of maximum, minimum and average.
（11）Key of ENTER
It is used to confirm a storage or reading of data.
（12）REL
It is used to select relative measurement.
（13）Key of
It is used to select a memory for storage of data obtained.
（14）E socket
It is used to connect with the grounding pole.
（15）P/S socket
It is used to connect with the auxiliary grounding pole.
（16）C/H socket
It is used to connect with the auxiliary grounding pole.
-7-
Users’ Guide for Earth Ground Resistance Tester
