Note (1): Driving the amplifier at 2 Ω channel / 4 Ω bridge mode in poor ventilation conditions may cause a thermal overload
protection. 2 Ω power is time limited by main circuit breaker.
Note (2): Continuous burst tone 20 ms (0dB) / 480 ms (-20 dB) in accordance with EIA RS-490 and IEC 60268-3 / IHF A-202)
Specifications subjected to change without prior notice (jun. 2014)
15. Technical features
Certificate of warranty (enclosed document)
The Conditions and Observations for the application of this Contract of Warranty are for all the territories
of Spanish.
For other countries, the specifications of each country must be complied with, as only the Representative
or National importer themselves can be held responsible for warranty terms.
For any claim of a Legal type, only the Ordinary Courts corresponding to the city of Terrassa (Barcelona-
Spain) will be valid.
Please follow the instructions on the last page of this manual. Please READ the instructions and conditions
gathered in the Warranty Certificate to fully take advantage of the After-Sales Service.
If you follow the instruction manual and recommendations, we are sure that this amplifier will always perform within the predetermined parame-
ters, ensuring its long life and total efficiency.
Other causes that could prevent the normal work of the amplifier can
also activate the PROTECTION. Under those circumstances, the installa-
tion has to be revised according to the basic principles described below:
- Disconnect all the connected peripheral equipments (sources,
pre-amplifiers, and loudspeakers). Leave the amplifier “alone” and verify
if the anomaly disappears or if it remains in only one channel or both.
- Temperature: Cooling (possible air obstruction. Check if the fans
are working and make an internal cleaning).
- Short circuit: Check the state of the loudspeaker line (possible
short circuit, disconnect and check if the anomaly disappears).
- C.C. at the output (DC): Possible serious breakdown. Contact an
authorized technical service.
In all cases it is recommended to go through all previous checkpoints
before contacting the authorized technical service and reporting the
observed problem.
HD800 HD1200 HD2000 HD3200 HD4000
Voltage Gain
32 dB
Input Sensitivity 1 V 1.25 V 1.74 V 2 V 1.88 V
Input Impedance 20 kΩ
Slew Rate +/-12 V/μs
Output Power (1 kHz - 0,1% THD)
2
Stereo 8 Ω 230 + 230 W 350 + 350 W 600 + 600 W 1000 + 1000 W 760 + 760 W
Stereo 4 Ω 400 + 400 W 600 + 600 W 1000 + 1000 W 1750 + 1750 W 1400 + 1400 W
Stereo 2 Ω
1
550 + 550 W 850 + 850 W 1500 + 1500 W 2500 + 2500 W 2300 + 2300 W
Bridge 8 Ω 800 W 1200 W 2000 W 3500 W 2850 W
Bridge 4 Ω
1
1100 W 1700 W 3000 W 5000 W 4600 W
Average Current draw (1/3 power)
2
3 A 4 A 5 A 6 A 7 A
Frequency Response 20 Hz - 20 kHz (0/-1 dB)
Damping Factor (1 kHz @ 8 Ω) 280 300 350 400 350
Crosstalk -60 dB -65 dB
S/N Ratio (A-weighted) -102 dB (A) -104 dB (A) -105 dB (A) -108 dB (A) -108 dB (A)
Mains 220 – 240 V AC- 50/60 Hz
Dimensions (HxWxD) 88 x 482 x 420 mm 88 x 482 x 420 mm 88 x 482 x 440 mm 88 x 482 x 440 mm 88 x 482 x 440 mm
Weight 14 kg 15 kg 18 kg 21 kg 18 kg
