6. TECHNICAL SHEETS
MAW-218/D7
Line Input (Balanced) Impedance
1.8 V 10k ohms
Mains
230V +/- 10%
Consumption at Maximum Power
12 A
Frequency Response
LF Usable bandwidth 30 Hz - 130 Hz (-10 dB) (1W, processed)
Sensitivity
LF (1W @ 1m) 103 dB SPL
Amplifier Power
LF 3000 W
Nominal Directivity (-6dB)
Horizontal omnidirectional
Vertical omnidirectional
System Output Continuous SPL
(Long Term)
One enclosure @ 3000 W 138 dB
Two enclosures @ 3000 W 144 dB
Four enclosures @ 3000 W 150 dB
Components
LF 2x18" Long excursion Neodymium Woofer (100mm Voice Coil)
Enclosure
Width 740 mm
Height 1042 mm
Deep 785 mm
Weight (net) 98 Kg
Connections 1x AC INPUT PowerCon
1x AC STACKINGOUTPUT PowerCon
1x INPUT XLR Balanced
1x LINK XLR Balanced
2x RJ45 for External PC Control
Material Birch plywood, 2mm Black- Painted Steel Grille
Finish Black (Acrylic resin, ecological water-based)
Rigging TA-STK210/218 (Optional)
