Exploded view and parts list (continued)
Par tion Q Pa Qty t # Order # Descrip ty rt # Order # Description
81 240-0041-081 Snap Ring 12 1 121 240-0041-121 Rotary Shaft 1
82 240-0041-082 Screw M4x30 2 122 240-0041-122 Chuck 1
83 240-0041-083 Wheel 1 123 240-0041-123 Clamp Clip 1
84 240-0041-084 Screw M5x8 1 124 240-0041-124 LED Light 1
85 240-0041-085 Motor 1 125 240-0041-125 Screw M6x16 4
86 240-0041-086 Tool Box Cover asher 6 1 126 240-0041-126 Spring W 5
87 240-0041-087 Dust Blower 1 127 240-0041-127 Air Hose 1
88 240-0041-088 Air Nozzle 1 128 240-0041-128 Pressure Plate 1
89 240-0041-089 Table Insert 1 129 240-0041-129 Air Bag 1
90 240-0041-090 Saw Table 1 130 240-0041-130 Spring Pin M4x8 1
91 240-0041-091 Bevel Scale 1 131 240-0041-131 Table Rock 1
92 240-0041-092 Gear 1 132 240-0041-132 Screw M5x16 2
93 240-0041-093 Bevel Adjustment Knob 1 133 240-0041-133 Screw M5x16 5
94 240-0041-094 Table Bevel Lock Handle 1 134 240-0041-134 Copper Sleeve 4
95 240-0041-095 Spring 1 135 240-0041-135 LED Circuit Board 1
96 240-0041-096 Bolt 1 136 240-0041-136 Screw ST2.9x6 2
97 240-0041-097 Bolt 1 137 240-0041-137 Lower Rocker Arm 1
98 240-0041-098 Spring Washer 8 6 138 240-0041-138 Light Switch 1
99 240-0041-099 Screw M8x20 2 139 240-0041-139 Chuck Key 1
100 240-0041-100 Lock Bolt 1 140 0041-140 rench 4 1 240- W
101 240-0041-101 Rotary Connect 141 0041-141 rench 5 1 1 240- W
102 240-0041-102 Locking Knob 142 0041-142 rench 3 1 1 240- W
103 240-0041-103 Roll Pin 1
104 240-0041-104 Spring 2
105 240-0041-105 Shaft 1
106 240-0041-106 Sawdust Port 1
107 240-0041-107 Screw M4x16 2
108 240-0041-108 Pointer 1
109 240-0041-109 Pointer Holder 1
110 240-0041-110 bracket 1
111 240-0041-111 Cord Clamp 1
112 240-0041-112 Spring Tube 1
113 240-0041-113 Flex Shaft 1
114 240-0041-114 Rotary Tool 1
115 240-0041-115 Nut M8 4
116 240-0041-116 Rubber Foot 4
117 240-0041-117 Washer 15 1
118 240-0041-118 Bearing 1
119 240-0041-119 Sleeve 1
120 240-0041-120 Bearing 1
