Assembly
and
adjustments
Unpacking (Fig. 1)
Unpack the scroll saw and all its parts, and compare against the list below. Do not discard the
carton or any packaging until the scroll saw is completely assembled.
CAUTION: Do not lift the saw by the arm that holds the blade. The saw will be damaged.
WARNING: To avoid injury from accidental starting, turn switch OFF and remove plug from
power source outlet before making any adjustments.
240-0041 (888)315-3080 10
A
Not shown:
Pin-less blade (1)
Allen wrench (3mm, 4mm & 5mm)
Extra brush (1 set)
Storage compartment (Fig. 2)
A storage location (1) for small accessories
Scroll saw
B Rotary tool
C Rotary table with dust port (Assembled on the scroll saw)
D Rotary table insert
E Chuck key
