18
NATURAL GAS CONVERSION
WARNING:
Place the grill on a flat, level surface.
Before the conversion, make sure all control knobs are in the OFF position, LP tank valve is
closed, and tank is disconnected from regulator and removed from grill.
21. Removed the R-pins at the back of main
burners to detach burners from bracket.
Lift
back of burners while sliding burners out of
firebox, disengaging burners from gas
valves as shown.
22. Unscrew the old LP orifice from each gas
valve with the orifice removal tool. Put a
new NG orifice on
to the valves and tighten
with tool. Repeat this step for all four
burners.
¶1.30mm Orifice
x4
Orifice removal tool
x1
2
1
2
1
To Next Page
