6
Hardware Used
FF
2
M3/16in Screw
x 5
ASSEMBLY INSTRUCTIONS
Hardware Used
1. Line up holes on the bracket of wheel kit (G) with the
corresponding holes on base (H), then insert M8 x15mm bolts
(AA) through holes. Hand tighten with M8 flange nuts (DD). Be
sure the wheel assembly is parallel to the base (H).
To protect heater from strong wind, anchor the base (H)
securely to the ground with screws.
a. Reverse the base (H), fix the ground bracket (PP) to the
base (H) with bolts (BB) and washers (LL) like picture shows.
b. Secure the ground bracket (PP) with nuts (HH).
c. Fix another two ground bracket
nuts (HH) , and reverse the base (H).
2. Fix the base bracket (OO) to the base (H) with screws (FF)
like picture shows.
.
1
WARNING
This product contains sharp edges on
the panels,cylinder housing and
handle please install with care.
AA
x 2
M8 Flange Nut
BB
DD
HH
LL
M6 x10mm Bolt
Nut M6
Φ6 Washer
AA
DD
H
G
BB
LL
HH
H
PP
M8 x15mm Bolt
x 6
x 2
x 6
x 6
OO
H
FF
PP
x 3
Ground Bracket
OO
Base Bracket
x 5
(PP) with bolts (BB) and
To Next Page
